Search for Crane Part number

(click on image to open PDF document)

Figures in which the part appears:
3228182-ETL (Grove GMK 5250L )
3228183-ETL (Grove GMK 5250L )
3298383-ETL (Grove GMK 5250L )

Also known as:
3327149, 03327149, 003327149
Parts for Grove GMK 4080-3, Figure 3228183-ETL:
Part Number 3327149: CONTACT FUSE
Pos nr Part number Description Weight in kg
1 2214703 CABLE (PER METER) 0.01
2 2214704 CABLE (PER METER) 1
3 1370445 CABLE (PER METER) 0.009
4 1370458 CABLE (PER METER) 0.060
5 2315700 CABLE 0.020
6 3327948 PLUG 0.001
7 1370454 INSULATING HOSE
8 4160043 RESISTOR
10 3323022 RECEPTACLE
11 2214828 RESISTOR
13 3318953 RECEPTACLE 0.002
14 1680204 RECEPTACLE 0.005
15 2311919 INSULATING SLEEVE 0.080
16 3007823 PLUG WITH CABLE 0.28
17 2318261 CABLE FLRY-B 0,5 BN (PER METER) 0.085
18 3046963 TIMER HOUSING 0.01
19 80013074 STRIP 0.015
20 3140913 CONTACT 0.005
21 3142252 CONTACT
22 3041216 SINGLE-LINE SEAL 0.01
23 3323941 PLUG HOUSING 5 PIN
24 3323937 RECEPTACLE
25 1204420 PLUG CASIGN 0.005
26 3041335 TIMER HOUSING
28 0554236 KREPP-SPLICING TAPE 0.01
29 7364100013 CONTACT FUSE
30 7689000503 PLUG SEAL 0.005
31 3323675 TIMER HOUSING
32 3320217 HOUSING 0.005
33 80003367 BUSH
34 80004700 SEAL 0.005
35 3142169 PLUG
36 3320247 PLUG
37 7826000087 SOCKET CONTACT 0.010
38 1683947 RECEPTACLE 0.001
39 3323023 INSULATING SLEEVE
40 3041339 SINGLE-LINE SEAL
41 3325424 SHRINK HOSE 0.015
43 2312363 MULTICORE CABLE END
44 3325977 TWISTED SHEATHED CAN BUS CABLE 1.558
45 1370455 INSULATING HOSE
46 3325812 HOUSING 0.010
47 3142172 CONTACT
48 3142435 CONTACT
49 3041218 SINGLE-LINE SEAL 0.001
50 3321643 SHRINK HOSE 0.07
52 3328033 FUSION TAPE 0.001
53 2318067 RESISTOR 0.005
56 3317968 BLIND PLUG 0.010
57 3046961 TIMER HOUSING 0.005
58 3327154 TIMER HOUSING 0.010
59 3318969 CONTACT SPRING 0.005
64 3319434 RECEPTACLE 0.005
67 2251769 MULTICORE CABLE END 0.001
70 3328529 CABLE
71 3328528 CABLE
72 3041032 INSULATING SLEEVE 0.001
73 1373416 RECEPTACLE
74 3041336 TIMER HOUSING
75 3327153 CONTACT FUSE 0.005
78 3317642 JUNIOR TIMER CONTAKT 0.005
79 3046960 TIMER HOUSING 0.005
80 3317689 CONTACT FUSE
81 4159134 100A CRIMP MODULE MALE
82 4159136 POWER CONTACT MALE 10MM²
83 3327150 CONTACT FUSE
84 3329807 PIN INSERT
85 3327149 CONTACT FUSE 0.005
86 3320715 CONTACT
87 3329805 BUSH INSERT
88 3320702 CONTACT
89 3320703 CONTACT
90 3320704 CONTACT 0.005
91 4159142 POWER CONTACT FEMALE 1,5MM²
92 3325231 PINTYP CABLE-SOCKET 0.005
93 3325230 CABLE EYE 0.001
94 0438064 PINTYP CABLE-SOCKET 0.002
97 3317915 BLIND PLUG 0.005
98 3317912 SOCKET CONTACT 0.005
99 3317913 SEAL 0.005
111 3325043 CABLE
112 0435766 PIPE CLAMP
113 2312364 MULTICORE CABLE END 0.001
114 3318970 CONTACT SPRING BAND 0.022
115 3325811 PROTECTIVE COVER 0.100
116 4159401 POWER CONTACT FEMALE 0,14-0,37 MM²
118 3320713 CONTACT
119 3320714 CONTACT 0.01
120 2313382 SILICON CABLE (PER METER)
121 3041856 SOCKET CONTACT 0.005
122 3041855 SINGLE-LINE SEAL (YELLOW) 0.005
123 3317924 PIN HOUSING 0.01
124 3125036 NOISE FILTER 0.62
125 0554056 EYELET, TUBE TYPE
126 4161001 100A CRIMP MODULE MALE
127 4161003 POWER CONTACT MALE 50MM2
128 3317917 SOCKET HOUSING 0.005
131 3046708 JUNIOR TIMER CONTAKT FOR SIGNLE FEED 0.005
132 3320685 CORRUGATED TUBE
133 4160890 PLUG HOUSING
* Selected parts are automatically added to your RFQ list *
3327149 Grove GMK 3060 CONTACT FUSE
