Parts for Krupp 70 GMT-AT, Figure 1685171-ETL:
Part Number 1205561: REPAIR KIT WEDGE
Pos nr Part number Description Weight in kg
1 1684582 AXLE DRIVE CPL
1.01 1584578 DIFFERENTIAL
1.02 1684107 BEVEL GEAR SET
1.03 1684579 DRIVE FLANGE
1.04 1684119 DRIVE-IN NUT 0.420
1.05 1684575 PRESSURE SWITCH 0.300
1.06 1684576 O-RING
1.09 1684574 SHIFTER FORK
1.12 1684580 GROOVED BALL-BEARING 0.780
1.13 0434985 RING,WELLENDICHT 0.05
1.14 1684139 BACK-UP WASHER
1.15 1684138 CIRCLIP 0.018
1.16 1684581 THROUGH DRIVE
3 1683290 DISTANCE RING
4 1679675 KNOKOUT SPINDLE
5 1679676 KNOKOUT SPINDLE
6 1573428 SHAFT NUT 0.001
7 1576585 TAPERED ROLLER BEARING 2.495
8 1576582 TAPERED ROLLER BEARING 3.250
9 0439215 ROTARY SHAFT SEAL
10 1201449 ROTARY SHAFT SEAL 0.148
11 1576543 WHEEL HUB 32
12 1576598 SIMPLEX BRAKE
12.02 0010946 BOLT SPRING
12.03 1576599 BRAKE SHOE WITH LINING 500X120 MM 8.910
12.03.01 1679680 BRAKE LINING 500X120 MM - 8 HOLES 1
12.03.02 0438047 RIVET 0.010
12.04 0107057 MECHNISM OF INCIINATION
12.04.01 1205561 REPAIR KIT WEDGE 0.001
12.04.02 1066738 REPAIR KIT ADJUSTMENT
12.04.03 1205562 REPAIR KIT SEAL 0.062
12.04.04 1366948 PRESSURE SPRING
12.04.05 1066949 PRESSURE SPRING
13 1679674 BRAKE DRUM
14 1684020 PLANETARY GEARING
14.01 1684094 PLANETARY HOUSING
14.02 1066962 O-RING 0.14
14.03 1684009 PLANET PINION
14.04 1684010 NEEDLES
14.05 1576857 O-RING 0.005
14.06 1576559 THRUST RING
14.07 1684011 PLAN ETARY BOLT
14.08 1684012 GEAR WHEEL
14.09 1684013 GEAR WHEEL
14.10 1684014 RING GEAR CARRIER
14.12 1576586 CIRCLIP
14.14 1576556 SET SCREW
14.15 0157589 GROOVE NUT
15 0551389 WHEEL STUD WITH NUT AND SPRING WASHER
