Parts for Grove GMK 7450, Figure 2196510027-ETL:
Part Number 1686517: BALL PIVOT, LEFT
Pos nr Part number Description Weight in kg
1 2315662 HALF-BLOCK HYDRAULIC STEERING 40
1.01 3044975 SET OF SEALS 0.11
2 2314945 STEERING LEVER
3 3011140 STEERING CYLINDER 7.62
3.01 3046014 STEERING CYLINDER (ZF)
3.01.01 3316083 SET OF SEALS 0.250
3.01.02 3316084 SET OF SMALL PARTS 0.12
3.02 3046015 STEERING CYLINDER (HENGSTLER)
3.02.08 3045894 SET OF SEALS 0.16
4 2212202 BALL PIVOT 2.400
5 2318446 STEERING CYLINDER 24.52
5.01 2312309 SET OF SEALS 0.27
6 1066826 BALL PIVOT 3.28
7 7601160014 STEERING ROD 13.200
8 2310017 STEERING LEVER
9 7601160005 STEERING ROD 12.900
9.01 1065009 BALL PIVOT, RIGHT 1.620
9.02 1064245 BALL PIVOT, LEFT 1.620
10 1369318 STEERING LEVER
11 2318843 STEERING LEVER 14.500
12 6601100013 STEERING LEVER
12.01 1371130 STEERING LEVER
13 7601160015 STEERING ROD 25.100
14 2214214 STEERING LEVER 17.400
14.01 1686516 BALL PIVOT, RIGHT 3.5
14.02 1686517 BALL PIVOT, LEFT 3.5
15 1575943 STEERING ROD
16 1371209 STEERING LEVER
19 4196710034 CLAMP 1.430
22 4196510019 COVER 0.690
24 3011901 PLATE
25 3011902 HOLDER 0.08
26 3011903 SWITCH ARM
27 3010856 GABLE HARNESS, ANGLE TRANSMITTER 0.62
27.01 3041961 ANGLE TRANSMITTER 0.980
28 2318373 CLAMP
29 3317200 ANGLE JOINT 0.05
31 6352100003 CONNECTION SIGNAL TRANSMITTER 0.520
31.01 7356100012 PLATEAL TRANSMITTER 0.250
31.03 3041587 WALL PLUG BOX 0.160
34 1925392 UNIVERSAL JOINT 0.980
35 7372100070 STEERING CYLINDER
35.01 3065710 FRONT DECKING 0.001
44 7601160010 STEERING LOCKING DEVICE 40.000
44.01 3322096 SET OF SEALS
44.02 3322097 PRESSURE SWITCH 0.001
44.03 3322098 PROTECTOR 0.001
44.04 3322099 BALL PIVOT 3.900
44.05 3043472 PRESSURE SPRING
45 2196710024 STEERING ARM
45.01 2196710023 STEERING ARM
45.02 2197500589 SHAFT, STEERING ARM
45.03 7069001193 CYLINDER ROLLER BEARING
45.08 7258000834 HUB CAP
46 2196710041 STEERING ARM
46.01 2196710044 STEERING ARM
46.07 7753001599 WIPER RING
47 2196710042 ROTATION ARM
47.01 2196710045 AXLE ARM
47.02 4196710046 AXLE PIN 3.430
47.05 6822100005 PRESSURE SLEEVE 0.220
47.06 6949100017 RETAINING WASHER 0.045
48 2196710043 ROTATION ARM
48.01 2196710047 AXLE ARM
48.02 4196710047 AXLE PIN 9.900
49 7300001018 CLAMP, MUFFLER 0.245
50 4196510025 COVER 0.430
51 4196510023 PLATE
52 4196510024 PLATE 0.350
* Selected parts are automatically added to your RFQ list *
1686517 Grove GMK 5100 BALL PIVOT, LEFT
