Search for Crane Part number
(click on image to open PDF document)
Figures in which the part appears:
Also known as:
3100409, 03100409, 003100409
3100409, 03100409, 003100409
Parts for Grove GMK 5220, Figure 3109840-ETL:
Part Number 3100409: JIB 29 IN
Part Number 3100409: JIB 29 IN
| Pos nr | Part number | Description | Weight in kg |
|---|---|---|---|
| 1 | 3100408 | JIB 37 IN | |
| 2 | 3100409 | JIB 29 IN | |
| 3 | 3100410 | SWING-AWAY JIB 21 IN | |
| 4 | 3112085 | SHEAVE HEAD | 121 |
| 5 | 3114460 | HEAVY DUTY JIB 2M, 19T | |
| 6 | 3116443 | HEAVY EQUIPMENT | 442 |
| 7 | 3153422 | 2. HEAD ROLLER, MOUNTING | |
| 8 | 3153423 | ROLLER PACKAGE 9 ROLLES | |
| 9 | 3145396 | SCHWERLASTSPITZE 2 M-38 | |
| 10 | 3188593 | HINGED JIB 12,5M CPL. |
