Search for Crane Part number
Parts for Grove GMK 4100-L, Figure 3202971-ETL:
Part Number 4155291: LOCK LEFT HAND
Pos nr Part number Description Weight in kg
1 3134899 DRIVERS CAB (SHELL)
2 3134900 ROOF WINDOW
3 3134901 BOLT
4 3134902 EDGE PROTECTION ROOF WINDOW
5 3134903 FRONT PANE 28
6 3134904 DROP WINDOW 22
7 3134905 DROP WINDOW 7
8 3134906 RAIL 0.29
9 3134907 SEALING
10 3134908 SEALING 0.001
11 3134909 SEALING
12 3134910 SEALING 0.22
13 3134911 DOWEL 0.001
14 3134912 PROTECTION 0.005
15 3134913 WINDOW GUIDE
16 3134914 WINDOW GUIDE
17 3134915 PROTECTION
18 3134916 HOLDER FOR WINDOW LIFTER 0.001
19 3134917 HOLDER FOR WINDOW LIFTER 0.001
20 3134918 WINDOW LIFTER, ELECTRIC LEFT 1.6
21 3134919 WINDOW LIFTER, ELECTRIC RIGHT 1.6
22 3134920 PLUG BOX (WINDOW LIFTER MOTOR) 0.020
23 3134921 DOORHANDLE OUTSIDE 0.360
24 3134922 PLATE 0.010
25 3134923 PLATE 0.006
26 3326143 BOLT 0.002
27 3134924 PLUG 0.005
28 3134925 LOCK LEFT HAND 0.011
29 3134926 LOCK RIGHT HAND 0.105
30 3134927 CLOSING BOLT 0.1
31 3134928 BOLT 0.001
32 3134929 PULL ROD 0.04
33 3134930 PULL ROD 0.04
34 3134934 CLAMP 0.001
35 3144643 TACKLE LH 0.015
36 3144644 TACKLE RH 0.065
37 3144646 DOOR OPERATION DRIVERS DOOR 0.110
38 3144647 DOOR OPERATION FRONT PASSENGER DOOR 0.110
39 3134939 COVERING LEFT 5
40 3134940 COVERING RIGHT 4
41 3134941 COVERING VENTILATION
42 3134942 COVERING HANDLE, LH 0.058
43 3134943 COVERING HANDLE, RIGHT 0.064
44 3144648 DOOR SEALING
45 4159804 DRIVER SEAT
46 4159805 CO-DRIVER SEAT
47 3065731 BRAKE SYSTEM
48 3144102 VARIANTS FOOT THROTTLE
49 3065732 STEERING DRIVERS CAB
50 3144686 E.- PARTS AXOR-DRIVERS CAB 0.001
51 3144696 MIRROR
52 3144703 SUN VISORS AND HANDLES
53 3065736 FRONT FLAP
54 3134948 WIPER SUPPORT CPL. 27.273
55 3134949 WIPER ARM CPL. 0.001
56 3065737 \MNDSCREEN WASHER SYSTEM
61 3134954 AIR HEATER
62 3144650 GRID
63 3134956 GRID
64 3134957 NOZZLE
65 3144651 CLAMP
66 3134959 HOSE
67 3144652 CLOCK
68 3134961 FRAME 0.02
69 3134962 AIR-CONDITIONING SYSTEM CPL.
70 3134963 CONTROL PANEL 0.001
71 3134964 PIPELINE CPL. 0.001
72 3134965 PRESSURE LINE CPL. 0.001
73 3134966 REFRIGERANT PIPE 0.030
74 3134967 LIQUID RESERVOIR 0.58
75 3134972 CONDENSER WATER HOSE
76 3134973 SLEEVE
77 3144654 HEATING FILTER CPL.
78 3134977 FLAP
79 3134978 GRID
80 3134979 HOSE
81 3144655 HOSE CLAMP
82 3134980 TRANSMITTING INSTRUMENT 0.001
83 3144680 COVERING AXOR DRIVERS CAB
84 4155291 LOCK LEFT HAND 0.24
85 4155292 LOCK RIGHT HAND 0.105
* Selected parts are automatically added to your RFQ list *
4155291 Grove GMK 5130-2 LOCK LEFT HAND
