Search for Crane Part number

(click on image to open PDF document)

Figures in which the part appears:
AT part (Grove )
6414000145 (Grove RT 60S )
2192800711 (Grove RT 9100 )
RT 9100 (Grove RT 9100 )
Also known as:
9543100004, 09543100004, 009543100004
Parts for Grove RT 60S, Figure 6414000145:
Part Number 9543100004: HOSE ASSY, 3/8 X 26
Pos nr Part number Description Weight in kg
7755904002 O-RING 0.005
2 2160800238 RADIATOR AND OIL COOLER
3 2160800230 ENGINE HOOD AND GRILL
4 2162800051 ANGLE, MOUNTING
5 6294001397 WIRING DIAGRAM
6 7300000011 CABLE CLAMP 0.036
7 4160600079 COVER
8 2162100003 BRACKET, REAR ENGINE MOUNTING
9 7064000007 BATTERY, 12 VOLT
10 6246000287 CABLE, BATTERY
11 7910002312 TUBE
12 6949000147 WASHER SPECIAL
13 7910002311 TUBE
14 9543100020 HOSE (3FT)
15 6850000080 STRAP, GROUND
16 7892000053 TERMINAL, BATTERY CABLE
17 7892000054 TERMINAL, BATTERY CABLE 1
18 7638000024 MOUNT, CENTER BONDED 4
19 7638000025 MOUNT, CENTER BONDED 6
20 9543100029 HOSE (1 1.540
21 7300000020 HOSE CLAMP
22 7300000013 CLAMP, HOSE
23 7850000064 TIE, CABLE (NATURAL)
24 7926000274 VALVE 2
25 7790140853 SCREW, SELF-TAPPING
26 7543000334 HOSE-RAD 2 IN ID X 16-3/4 IN G 1
27 9543100004 HOSE ASSY, 3/8 X 26
28 7949000148 FLATWASHER
29 7013000072 ADAPTER 0.907
30 6200400292 TUBE
31 7013000156 ELBOW 1.893
32 7300000044 CLAMP, HOSE
33 2160800197 CLEANER ASSEMBLY - AIR
34 7535000025 HOOD, AIR INLET 1
35 7056000004 BAND, AIR CLEANER MOUNTING
36 9543100003 HOSE
37 7300000036 CLAMP, MUFFLER 4
38 6650240321 NIPPLE, PIPE
39 7444242470 ELBOW
40 7443000041 FITTING, REDUCER
41 7642000006 MUFFLER
42 7444002844 COUPLING
43 7300000047 MUFFLER CLAMP 3
44 6418000023 EXTENSION, MUFFLER
45 7542008403 HOSE ASSY
47 7445080404 SWIVELADAPTER UNION
48 7445040407 ADAPTOR
49 7444040256 BUSHING, REDUCER
50 7660221600 LOCKNUT, HEX
51 7115161050 HEX HD BOLT 0.103
52 7660160000 NUT, HEX 0.018
53 7950160050 LOCK WASHER 3/8" PEG 0.080
54 7950160140 LOCKWASHER 3/8" I.D.
55 7115160850 BOLT HEX 3/R-16 HC X 1" - CR0 5 0.018
56 7115203250 HEX HEAD BOLT
57 7660201600 LOCKNUT, HEX
58 7115223650 CAP SCREW,
59 4160600080 SHIM,
60 7437000044 PRIMARY FUEL FILTER
61 7445060404 ADAPTER, SWIVEL
62 6030000383 ANGLE, MOUNTING
63 7445060401 STRA SWIVEL ADP
64 7542002403 HOSE ASY
76 7356000015 TORQUE CONV. 116.122
77 2160800112 BRACKET WELD,MTG - LH
78 2160800115 BRACKET WELD,MTG - RH
79 7722000088 PUMP ASSEMBLY - TRIPLE
80 4175800151 BRACKET, MOUNTING
81 2126800091 MTG BRACKET WELD
82 7593000089 CONTROL LEVER
83 2126800090 WELD BRKT CONTROL LEVER MOUNTI
84 7722000073 STEER PUMP 7722000035 3.360
85 7352000016 UNIT, SENDING
86 7352000009 SENDER, TEMPERATU FE
87 7372000303 CYLINDER ASSEMBLY - THROTTLE 1.540
88 7308000042 YOKE
89 9543100013 HOSE 0.394
90 7750000005 STARTER SOLENOI 0.600
91 7352000038 OIL TEMP SENDER 0.090
93 7406000071 ELBOW
94 7794000288 GASKET
95 7502000002 AIR GOVERNER
96 7794000139 GASKET, AIR GOVERNOR
99 6200060703 BUSHING
105 7445040401 SWIVEL ADPT UNI 0.038
106 7444020154 BUSHING
131 7115152250 CAP SCREW,
132 7950150050 LOCK WASHER 5116" RED 0.002
133 7115151450 CAPSCREW
134 7115152450 CAP SCREW
135 7794000237 EXHAUST GASKET
137 6570161833 PIN
139 7950150161 FLATWASHER 5/1" I.D.
140 7115150850 CAPSCREW 0.011
141 7115141050 CAPSCREW,
142 7115181250 CAPSCREW 0.045
143 7356000020 ASSY CONV.DRIVE
144 7356000019 SLEEVE HUBDRIVE
I 6414000146 CAT 3208 ENG. ASSY.
I 6414000176 ENGINE ASSEMBLY
