Figures in which the part appears:
Also known as:
9049112011, 09049112011, 009049112011
9049112011, 09049112011, 009049112011
Parts for Grove RT 530E, Figure 7049101385.5:
Part Number 9049112011: KIT, BRAKE LINING
Part Number 9049112011: KIT, BRAKE LINING
| Pos nr | Part number | Description | Weight in kg |
|---|---|---|---|
| 2 | 9049107402 | PLUG | |
| 3 | 9049107151 | RING, BACK-UP | 0.004 |
| 4 | 9049109065 | O-RING | 0.010 |
| 5 | 9049109064 | COVER, SEAL DUST | 0.013 |
| 6 | 9049107148 | PISTON | 1.520 |
| 7 | 9049109066 | O-RING | 0.004 |
| 8 | 9049107152 | CAP HEAD, CYLINDER | |
| 9 | 9049112011 | KIT, BRAKE LINING | 4.884 |
| 10 | 9049110945 | PLATE | |
| 11 | 9049109048 | CAP SCREW | |
| 12 | 9049107157 | PLUG | |
| 13 | 9049107154 | BLEEDER | 0. |
