Search for Crane Part number

(click on image to open PDF document)

Figures in which the part appears:
RT 760E (Grove RT 760E )
6978100838 (Grove RT 875E )
Also known as:
7352100029, 07352100029, 007352100029
Parts for Grove RT 875E, Figure 6978100838:
Part Number 7352100029: MODULE, CARRIER CONTROL
Pos nr Part number Description Weight in kg
9581100396 BULB, HALOGEN 0.022
7172000546 BOOT 0.005
7689000704 PIN 0.02
9581100201 GROMMET
9872100244 KEY 0.120
9581100401 PLUG
9581100402 LAMP
9581100403 PLUG
9581100426 LAMPISEAL RED 12V.
1 6512100805 HARNESS ASSEMBLY - CARRIER
2 7300000249 CLAMP, TUBING
3 7581001361 LIGHT, WORK 2.934
4 7581100013 LIGHT, TURN TAIL LED VELLOW 0.290
5 7581100012 STOP,TURN & TAIL LED RED LIGHT 0.278
6 7025000836 ALARM, BACK-UP 0.750
7 7126151253 CAP SCREW, M6 X 25MM HEX HEAD FR
8 7300000399 CLAMP, TUBING
9 7126151353 CAP SCREW, M6X30 HEX HEAD
10 7352100029 MODULE, CARRIER CONTROL 6.440
11 7486002973 HOURMETER 0.220
12 6679100155 PANEL ASSEMBLY - ENGINE RELAYS
13 7300000408 CLAMP, TUBING
14 7300000402 CLAMP, TUBING
15 7300000405 CLAMP, TUBING
16 7300000404 PIPE CLAMP CPL.
17 7300000400 CLAMP, 500 ID
18 7126151153 CAP SCREW, M6X20 HEX HEAD
20 7951150210 LOCKWASHER 6MM I.D. 0.16
21 7661150003 6 MM DIA NORM 0.008
22 7111040410 SCREW, MACHINE
23 7950040141 WASHER 7/64" I.D.
24 7950040050 LOCKWASHER 7/64" I.D.
25 7660041100 NUT, HEX 0.001
26 7246002555 CABLE ASSEMBLY 0.012
27 7660160000 NUT, HEX 0.018
28 7115161250 CAPSCREW
29 7950160350 LOCKWASHER 3/8" I.D.
30 8594000027 WRAP, HOSE
31 7850000208 TIE, CABLE 1
32 7064000070 BATTERY, 12 VOLT 27
33 4174110248 PLATE, MOUNTING
34 7482000555 FUSE, 100 AMP 0.1
35 7086001082 HOLDER, FUSE
36 6059100001 BAR, BUSS
37 7300001002 BATTERY, HOLD-DOWN
38 6865147860 STUD
39 7950140161 WASHER, 1/4" I.D. FLAT WIDE 0.024
40 7950140050 WASHER, LOOK 1/4" 0.006
41 7660140000 NUT. 1/4-20 HEX 0.004
42 7950160050 WASHER, LOOK 3/8" I.D. 0.080
43 7660160200 JAM NUT
44 7111100807 SCREW, MACHINE
45 7660101100 NUT, HEX
46 7950100050 #10 DIA HELICAL 0.005
47 7950100141 #10 DIA PLAIN W 0.004
48 7111100611 SCREW, MACHINE
49 7300000100 CLAMP, TUBING
50 7246100249 KIT - CABLE (BATTERY)
51 7872001363 SWITCH, BATTERY DISCONNECT 0.800
52 7300000098 CLAMP, TUBING
53 4189110144 COVER
54 7659190019 NUT, M6 X 1.00 RETAINING
55 7950150161 FLATWASHER 5/1" I.D.
56 7115160850 CAPSCREW 0.018
57 7300000406 CLAMP, TUBING
