Grove 9333104035 - REEL ASSEMBLY

Search for Crane Part number

(click on image to open PDF document)

Figures in which the part appears:

Also known as:
9333104035, 09333104035, 009333104035

Parts for Grove RT 875E, Figure 7598100132:
Part Number 9333104035: REEL ASSEMBLY - LWG509 CABLE

Pos nr	Part number	Description	Weight in kg
1	9333104035	REEL ASSEMBLY - LWG509 CABLE	25
2	9333101437	ROLLER GUIDE ASSY	0.594
3	9333101435	CABLE GUIDE ASSY	0.200
4	9333103094	CLAMP	0.010
5	9333103697	CABLE	0.180
6	9333102620	61	0.030
7	9333103872	CAN BUS ASSEMBLY	1.15
8	9333103565	BOX	0.420
9	9333102230	LIFTING LIMIT SWITCH	1.220
10	9333102633	A2B FLAG ASSY	0.800
11	9333102235	ELECTRIC CONDUIT PER FEET	0.402
12	9333102765	CONNECTOR ASSEMBLY DUMMY	0.136
13	7296000004	CORROSION INHIBITOR	0.140
14	9333103768	NUT, EVE	0.110
