Search for Crane Part number

(click on image to open PDF document)

Figures in which the part appears:
1601-22 (Faun ATF 65G-4 )
Also known as:
997-070-07310, 99707007310, 099707007310, 0099707007310, 0997-070-07310, 00997-070-07310
Parts for Faun ATF 65G-4, Figure 1601-22:
Part Number 997-070-07310: 4-CIRCUIT PROTECTION VALVE
Pos nr Part number Description
1 997-077-91020 AIR TANK BRACKET
2 997-084-57604 AIR RESERVOIR
3 997-000-56668 HEX BOLT
4 997-084-08970 DISC
14 997-011-48092 HEX BOLT
15 997-009-33293 HEX BOLT
16 997-084-75943 LOCK NUT
18 997-070-07540 AIR DEHUMIDIFIER
19 997-070-04743 OUTLET SILENCER
20 997-070-07310 4-CIRCUIT PROTECTION VALVE
21 997-077-70524 ANGLE
22 997-000-54405 HEX BOLT
25 997-000-63281 HEX BOLT
25 997-070-16330 THREAD CUTTING SCREW
26 997-008-96690 O-RING
27 997-005-05260 LOCK NUT
28 997-084-08994 DISC
30 997-084-11976 TEST CONNECTION
31 997-084-10065 ACCUMUL FILL VALVE
32 997-070-17773 PRESSURE SWITCH
33 997-070-17774 PRESSURE SWITCH
34 997-070-07881 PRESSURE SWITCH
35 997-077-30540 PRESSURE SWITCH
50 997-070-05436 SCREWED UNION
51 997-000-15669 HOLLOW SCREW
52 997-005-90593 RING
53 997-000-09109 O-RING
54 997-070-05457 SCREWED UNION
56 997-016-36028 L-SOCKET
56 099-708-43623 L-SOCKET
57 997-070-05255 PLUG COUPLING
57 997-070-05475 L-COUPLING
58 997-070-05467 ANGLE UNION
58 997-070-05469 ANGLE UNION
59 997-084-10880 SCREWED SOCKET
59 997-070-17276 CONNECTING FITTING
60 997-019-91910 L-SOCKET
60 997-070-19353 L-COUPLING
61 997-077-23989 REDUCER 15/6
61 997-070-19758 UNION
62 997-084-74887 SOCKET
62 997-070-19021 ANGLE UNION
63 997-070-05256 PLUG COUPLING (16X2)
64 997-070-14034 SCREWED UNION
65 997-077-23930 UNION
66 997-070-05468 ANGLE UNION
67 997-017-68846 BULKHEAD SOCKET
67 997-084-10919 BULKHEAD SOCKET
68 997-084-74829 BULKHEAD SOCKET
69 997-016-36655 SCREWED SOCKET
70 997-070-05435 SCREWED UNION
71 997-084-11239 SOCKET
71 997-019-83889 L-SOCKET
72 997-077-23927 UNION
73 997-084-11414 THREADED PLUG
74 997-000-34847 RING
75 997-014-05182 O-RING
76 997-084-11013 BULKHEAD SOCKET
77 997-070-05472 L-COUPLING
78 997-070-05253 PLUG COUPLING
79 997-000-69810 NUT
80 997-084-03764 LOCK WASHER
81 997-070-05470 T-CONNECTOR
90 997-077-84129 BRAKE LINE SET COFLSISTING OF ITEM 91 92
